Die cutting unit
1) .Die-cutting roller adopt high quality casting material, wall thickness is 30 mm, with good quality and dynamic balancing correction, hard chromium plating.
2) 2).Main body wallboard adopt high quality cast iron material, wall thickness is 50 mm,processing by large-scale machining center.
3) 3).Soft roller automatically repair institutions improve gluesheath of repeated use, can repair 3-4 times.
4) 4).Imported Taiwan super resistant polyurethane rubber gasket, convenient installation, the die cutting times can up to 120 million times.
|
Model of Smooth Operation High |
UNIT |
1200X2200/2400/2600 |
1400X2200/2400/2600 |
1600X2400/2600/2800 |
|
Speed Rotary Die Cutting Machine |
||||
|
Max. cardboard size |
MM |
1200 x 2000/2200/2400 |
1400 x 2000/2200/2400 |
1600 x 2200/2400/2600 |
|
Min. cardboard size |
MM |
350x600 |
400x600 |
450x600 |
|
cardboard thickness |
MM |
2-11 |
2-11 |
2-11 |
|
Design speed |
pcs/min |
160 |
160 |
160 |
|
Economic speed |
pcs/min |
80-140 |
80-140 |
80-140 |
|
Max. die cutting size |
MM |
1200 x 1950/2150/2350 |
1400X1950/2150/2350 |
1600X2150/2350/2550 |
|
Attachment mould roller diameter |
MM |
360 |
432 |
487 |
